The process: freezing, drying, desorption
Freeze drying (lyophilization)
A dehydration method in which frozen product is dried under vacuum: water leaves as vapor without ever becoming liquid. The technical term is lyophilization — the two words are interchangeable in food production, though lyophilization appears more often in pharmaceutical and laboratory contexts.
Freezing
Stage one of the process. The product is frozen solid — typically well below −30 °C — so that all free water becomes ice before drying begins. Freezing quality decides the final structure: fast, deep freezing makes small ice crystals and a fine texture; slow or partial freezing makes large crystals that can damage cell structure and leave a coarse, fragile product.
Sublimation
The phase change at the heart of freeze drying: ice turning directly into water vapor, skipping the liquid phase. Because there is no liquid water moving through the product, the shape, color, and cell structure stay intact — this is why freeze-dried strawberries still look like strawberries. Sublimation only happens under deep vacuum and below the product's critical temperature.
Triple point
The temperature and pressure at which water can exist as solid, liquid, and vapor at once (0.01 °C, 611 Pa). Freeze drying operates below the triple point, in the region where liquid water cannot exist — which is what forces ice to sublimate instead of melt. When a spec sheet says "deep vacuum," this is the physics it relies on.
Primary drying
Stage two of the process, where the frozen (free) water is removed by sublimation under vacuum. This is the longest stage and removes the majority of the water. The operator's main control is keeping product temperature safely below its critical point while sublimation runs — aggressive heating here causes melt-back and collapse.
Secondary drying
Stage three, where bound water — moisture held in the product's structure that never froze — is driven off with gentle heat (shelf temperatures up to around 80 °C on industrial machines). Primary drying sets the structure; secondary drying sets the final moisture content. Most of the cycle-time saving that suppliers promise comes from a well-tuned secondary drying phase.
Desorption
The release of bound water from the product's surfaces during secondary drying. If a datasheet says a machine "desorbs to 2% moisture," it means the secondary drying stage can drive bound moisture down to that level — the practical meaning of a complete dry.
Eutectic temperature
The temperature below which a frozen product's water-solute mixture is fully solid. During primary drying, the product must stay below this temperature — cross it and the structure softens, leading to melt-back and collapse. Knowing the eutectic point of your product is the single most important input to writing a safe drying recipe.
The quality terms: what can go right or wrong
Residual moisture (final moisture content)
The water left in the product after drying. It is the single biggest determinant of shelf life and crispness: higher residual moisture means faster quality loss. Industrial cycles target a low, validated final moisture for each product, and batches should be packed in moisture-proof barrier packaging immediately after discharge, because dried product reabsorbs ambient moisture quickly.
Moisture content (initial)
The water in the raw product before drying — typically 80–90% for fruits and vegetables. Together with product thickness and target residual moisture, it decides how long the cycle runs. Comparing two quotes or two cycles is only fair when initial moisture is stated.
Melt-back
A drying defect: ice inside the product melts instead of sublimating, usually because product temperature crossed the eutectic point during primary drying. The result is a dense, shrunken, poor-rehydrating product. The fix is a gentler shelf-temperature ramp and verified vacuum integrity.
Collapse
The visible form of melt-back damage: the product's structure caves in, losing its shape and much of its ability to rehydrate. Collapse is the classic sign of an overheated primary drying stage. It is a recipe problem, not a raw-material problem — the same product dries perfectly under a correct recipe.
Case hardening
A surface defect where the outside of a piece dries into a hard shell that traps moisture inside. More common in hot-air drying than freeze drying, but it can appear in freeze drying when the secondary drying ramp is too aggressive. The trapped core moisture later ruins shelf life and can cause spoilage.
Rehydration ratio
How completely a dried product returns toward its fresh weight and texture when water is added. A high rehydration ratio is the practical proof of a good cycle: intact cell structure (from proper sublimation) absorbs water readily. Poor rehydration usually traces to collapse, melt-back, or excessive heat in secondary drying.
The machine: chamber, vacuum, and controls
Shelf area
The usable heated surface inside the chamber, measured in square meters (m²) — the standard way industrial freeze dryers are sized. Shelf area × loading density × batches per week = real output. For reference: 20.16 m² (QS-FD-20, ~200 kg/batch), 103.68 m² (QS-FD-100, ~1 t/batch), 207.36 m² (QS-FD-200, ~2 t/batch). Specifications are for reference only and are subject to the final supplied equipment.
Tray load (loading density)
How much product is placed on each tray and how thick the layer is. Thin, even loads dry fastest; thick or densely packed loads can add many hours to the cycle. Most "slow machine" complaints turn out to be loading problems.
Batch capacity
The amount of product processed in one cycle — usually quoted as fresh weight per batch (~200 kg, ~1 t, ~2 t on the QS class machines). Distinguish it from finished-product weight: a 1-tonne fresh batch of fruit yields a fraction of that in dried product.
Vacuum level
How deep the vacuum inside the chamber is, usually expressed in pascals (Pa). Deeper vacuum lowers the boiling/sublimation point and speeds primary drying. If the machine cannot reach its target vacuum, the usual suspects are door seals, gasket condition, and vacuum pump oil — in that order.
Condenser (cold trap)
The refrigerated surface inside the machine that captures the water vapor leaving the product — freezing it out of the gas stream before it reaches the vacuum pumps. A condenser that ices up fully or is defrosted late is a common cause of slow cycles and wet batches.
Square chamber
A rectangular drying chamber (as opposed to round). Square chambers use floor space more efficiently and are easier to load with standard 400 × 600 mm trays — the reason industrial food machines are built this way. (All QS freeze dryers use square SUS304 chambers.)
Shelf temperature vs product temperature
Shelf temperature is what the machine's heaters deliver; product temperature is what the food actually experiences. During primary drying they can differ by 20 °C or more, because sublimation absorbs heat and keeps the product colder than the shelf. Experienced operators control the cycle by product temperature — shelf temperature is only the input, not the result.
PLC recipe
The programmed drying cycle stored in the machine's controller (Siemens S7-200 class on QS machines): temperature ramps, vacuum targets, stage durations, and alarm limits. A validated recipe per product is what turns a machine into a production line — running every product on one generic recipe is the fastest way to inconsistent quality.
Roots + screw vacuum pumps
The two-stage pump combination used on industrial machines: a Roots blower for high pumping speed at medium vacuum, backed by a screw pump for the deep-vacuum stage. The combination reaches and holds the deep vacuum that sublimation needs, and does it quietly and reliably enough for continuous production.
Frequently asked questions
What is the difference between primary drying and secondary drying?
Primary drying removes frozen water by sublimation — ice to vapor under vacuum — and takes most of the water out. Secondary drying uses gentle heat (up to ~80 °C shelf temperature on industrial machines) to remove bound water that never froze. Primary drying sets the structure; secondary drying sets the final moisture content.
Why is shelf temperature different from product temperature?
Shelf temperature is what the heaters deliver; product temperature is what the food experiences. During primary drying they can differ by 20 °C or more because sublimation absorbs heat and keeps the product colder. Control the cycle by product temperature — that is how operators avoid melt-back and collapse.
What is residual moisture, and why does it matter?
Residual moisture is the water left after drying — the single biggest determinant of shelf life and crispness. Dry to a low, validated final moisture for each product, and pack in moisture-proof barrier packaging immediately after discharge.
What causes freeze-dried products to collapse?
Collapse happens when product temperature exceeds its critical (eutectic) temperature during primary drying — the structure softens and loses shape. The usual causes are ramping shelf temperature too fast or a vacuum fault slowing sublimation. The fix is a gentler recipe and verified vacuum integrity.
What is lyophilization?
Lyophilization is the technical term for freeze drying — the same three-stage process of freezing, primary drying (sublimation under vacuum), and secondary drying (desorption of bound water). In food production the two words are interchangeable.
